2000mm Jumbo Paper Roll Slitter Rewinder & Glue Lamination Machine | HX-2000CSJ

Double-sided glue lamination system for strong multi-ply bonding and enhanced softness
High-speed operation up to 180 m/min for efficient large-scale production
Supports jumbo roll width up to 2000 mm to maximize output capacity
Produces large finished rolls up to 1200 mm diameter for industrial supply chains
Precision slitting with minimum width of 150 mm for flexible product formats
Stable tension control system ensures smooth processing of multi-layer materials
Heavy-duty structure (approx. 8000 kg) guarantees long-term reliability and stability

Product Detail

Premium Multi-Ply Production with Glue Lamination

Elevate your product portfolio to the premium tier with the HX-2000CSJ, the definitive solution for high-bulk, multi-ply tissue production. This advanced paper roll slitter rewinder features an integrated double-sided glue lamination unit, enabling you to bond multiple plies into ultra-absorbent, luxury kitchen towels and bath tissues. For manufacturers targeting the high-end retail and professional wiping markets, this machine provides the necessary technology to produce superior, point-to-point embossed products.

Sophisticated Lamination & Slitting Technology

Double-Sided Embossing & Gluing: Features independent pressure control for embossing. The glue unit starts automatically during operation and separates when stopped, ensuring clean, efficient lamination without adhesive buildup.
Precision Slitting at 2000mm Width: Designed to maximize the output of 2000mm wide jumbo rolls. The integrated slitting unit delivers precise, clean edges for professional-grade finished rolls.
Dynamic Tension Control: Utilizing a flat-belt unwinding system and stepless speed adjustment, the machine maintains perfect paper tension even when processing high-bulk, multi-ply materials.
Large-Diameter Output Capacity: Engineered to produce finished rolls with diameters up to 1200mm, making it ideal for high-volume commercial and industrial supply chains.

Target Application Scenarios

Premium Commercial Hygiene: Manufacturing of luxury multi-ply toilet rolls for high-end hotels and corporate offices.
High-Absorbency Kitchen Towels: Production of laminated kitchen paper with superior liquid retention and strength.
Industrial Wiping Solutions: Heavy-duty, multi-layer wiping rolls for professional laboratories and workshops.

Technical Specification

Metric	Data Profile
Max Production Speed	130 - 180 m/min
Jumbo Roll Max Width	2000 mm
Finished Roll Diameter	0 - 1200 mm (Adjustable)
Min Slitting Width	150 mm
Power Configuration	3 KW (Main Drive)
Total Equipment Weight	Approx. 8,000 kg
Dimensions (LWH)	11000mm × 2800mm × 2500mm

Huaxun Machinery: Your Partner in High-End Converting

Recognized as one of the elite napkin machine manufacturers, Huaxun (Fujian) Machinery excels in high-complexity tissue solutions. Our HX-2000CSJ combines manufacturing efficiency with international quality standards. We empower global hygiene brands with high-ROI machinery and a reliable supply chain, ensuring your facility remains competitive in the luxury tissue segment.
