1350mm Small Jumbo Paper Roll Slitter Rewinder Machine | HX-1350F

Optimized 1575mm width to reduce waste and maximize output
Integrated embossing and adjustable perforation (100–150mm) for premium tissue quality
Advanced tension control system for smooth, break-free operation at up to 180m/min
Flexible rewinding with adjustable tightness and max 300mm roll diameter
Fully automated slitting and rewinding for continuous, labor-saving production
Ideal for commercial kitchen towel and bath tissue manufacturing

Product Detail

Versatile Solution for Commercial Jumbo Roll Tissue (JRT)

Transform standard parent rolls into high-demand commercial tissue with the HX-1350F. This roll slitter rewinder is purpose-built to meet the strict requirements of the hotel and office supply sectors, delivering a one-step solution for producing Small Jumbo Rolls (JRT). By combining precision embossing and adjustable perforation in a compact 1350mm framework, it allows manufacturers to capture the commercial hygiene market with minimal material waste and maximum output.

Engineering Highlights & Performance Gains

Optimized 1575mm Processing Width: Purpose-built to maximize the utility of 1575mm jumbo rolls, reducing side-waste and improving the net output of every roll.
Precision Embossing & Perforation: Features a heavy-duty embossing unit that enhances bulk and softness. The perforation system is fully adjustable (100-150mm), ensuring clean tear-offs for end-users.
Advanced Tension Control System: Utilizing a flat-belt drive for unwinding and stepless speed regulation, the machine maintains perfect web tension, preventing paper breaks even at its peak speed of 180m/min.
Flexible Rewinding Parameters: Equipped with an air-swelling shaft, the HX-1575F allows for the independent adjustment of winding tightness, producing finished rolls with diameters up to 300mm.
Streamlined "One-Step" Operation: From raw paper to slit finished rolls, the entire process is automated, minimizing manual intervention and ensuring high-speed, consistent output.

Detailed Technical Specifications

Feature	Technical Data
Production Speed	130 - 180 m/min
Max Rewinding Diameter	300 mm (Adjustable)
Maximum Width of Raw Paper	1575 mm
Jumbo Roll Diameter	Up to 1200 mm
Perforation Distance	100 - 150 mm (Adjustable)
Power Supply	3KW (380V 50HZ, 3-Phase)
Machine Weight	Approx. 2.2 Tons
Overall Dimensions	4000mm × 2300mm × 1600mm

Why Global Brands Choose Huaxun Machinery

As one of the leading napkin making machine supplier, Huaxun (Fujian) Machinery focuses on more than just equipment assembly; we deliver industrial-grade stability. Our facility in China utilizes precision CNC machining to ensure that every roller and blade meets G3.2 dynamic balance standards. Whether you are expanding a facility or starting a new production line, our team provides high-ROI machinery backed by decades of technical expertise and comprehensive global after-sales support.
